Model Name |
M24A6 |
||
|
LCD Panel (VA) |
Display size |
23.6" Diagonal White LED-Backlight |
|
|
Brightness(Typical) |
220cd/m2 (Typical) |
||
|
NTSC |
72% |
||
|
Contrast(Typical) |
3000:1 (Typical) |
||
|
Pixel Pitch |
0.2715(H)X0.2715(V) |
||
|
Resolution (H x V) |
1920*1080 |
||
|
Aspect Ratio |
16:09 |
||
|
Response Time(Typical) |
25ms (Typ.) GTG 12ms |
||
|
View Angles LR,UD(CR>10) |
H 178/ V 178 |
||
|
Panel Surface |
Anti-glare |
||
|
Display Colors |
16.7M colors |
||
|
PC Input Range |
Max. display frequency |
1920*1080 /75 Hz |
|
|
(Resolution H*V/Fv) |
|||
|
|
|||
|
Interface |
Input 1 |
VGA |
|
|
Input 2 |
HDMI |
||
|
Output |
Speaker(Typic ) |
|
|
|
Terminal |
|||
|
Power |
Consumption(Typical) |
On: < 30W |
|
|
Standby<=0.5W, Off<=0.5W |
|||
|
Power Range |
AC 100-240V 50/60Hz |
||
|
Power Mode |
Power on : Blue (LED) |
||
|
Indicator Light |
Power saving : Blue Flicker (LED) |
||
|
Operating |
Temperature |
0℃ ~ 40℃ |
|
|
Condition |
Humidity |
20% ~ 85%, non-condensing |
|
|
Physical |
Dimension |
539.20*398.84*192mm |
|
|
(W*D*H) |
|||
|
Packing Dimension |
617x132x443mm |
||
|
(W*D*H) |
|||
|
Net Weight |
2.9Kg |
||
|
Gross Weight |
4.1Kg |
||
|
Tilt |
-5∘~ 15∘ |
||
|
Kensington Lock |
Yes |
||
|
VESA Mounting |
75*75mm |
||
|
Controls |
Front Control |
Menu, Bri (-), Vol(+) Auto/Enter, Power |
|
|
On Screen Display |
HKC Standard OSD format |
||
|
Color |
WARM,COOL,User Mode |
||
|
Preset Mode |
PC, Movie, Game, ECO Modes |
||
|
Accessory |
Adapter |
Yes (1.5M) 12V 2.5A |
|
|
HDMI Cable |
Yes (1.5M) |
||
|
User Manual(Paper) |
YES |
||
